AVR ExeGate Master Turbo AVS-8000
Specification
| Common parameter | |
| Full output power, VA | 8000 |
| Active output power, W | 8000 |
| Installation method | Wall installation |
| Type | Relay voltage regulator |
| Operating mode indication | |
| Indication of input/output parameters | LCD |
| The input voltage is below the permissible range | The delay mode indicator on the display |
| The stabilizer is working to increase the input voltage | The delay mode indicator on the display |
| The input voltage is above the permissible range, the stabilizer works to lower the input voltage | The delay mode indicator on the display |
| The stabilizer works to lower the input voltage | The delay mode indicator on the display |
| Delaying (Output is being suppressed) | The delay mode indicator on the display |
| Input and output parameters | |
| Input Voltage, V | 100-265 |
| Output Voltage, V | 220±8% |
| Response time, ms | 5-7 |
| Efficiency | 98% |
| Load connection | 2*Schuko + 5P terminal block |
| Location of outlets | In the side panel |
| Child protection | Yes |
| Input Frequency, Hz | 50 |
| Maximum input current, A | 40 |
| Other parameters | |
| Power | 5P terminal block |
| Surge Protection | Overvoltage / undervoltage, high voltage impulse, short circuit, overload and overheat protection. |
| Enironmental | Operating Environment, °C, operating Relative Humidity, % |
| Delivery set | AVR, manual, mounting kit, template |
| Product size, mm | 320x140x265 |
| Net weight, kg | 10,3 |
| Gross weight, kg | 11,5 |
| P/N | EX291750 |
| EAN | 4895205129436 |
