3U330-02

Specification

Type	3U
Motherboard Support	miniITX, mATX, ATX
Max. motherboard size, mm	244x305
Drive Bay:
Ext. 5.25"	1 (or 1 x 3.5")
Int. 3.5"	2
Int. 2.5"	2 (or 1 x 3.5")
Dust	Front panel is equipped with dust filters
Front I/O Ports	2 x USB 2.0
Control &Indicator, LED	1 x Power, 1 x HDD
Switch	POWER, RESET
Expansion Slots	4
Cooling System:	2 x 6 cm fan front, 2 x 6 cm side (opt.), 1 x 6 cm rear (opt.)
PSU	ATX not exceed length140mm
Chassis material	1.2 mm steel
Cases color	Black
Chassis color	Silver
Dimensions chassis (D x W x H), mm	300 x 430 x 133
Dimensions (D x W x H), mm	340 x 482 x 133
Net Weight w/o PSU / with PSU, kg	5,3/6,15
