2U420-06
Specification
| Type | 2U |
| Motherboard Support | miniITX, mATX, ATX (together with 1U or 2U Power Supply) |
| Max. motherboard size, mm | 305x244 (244x244 together with ATX Power Supply) |
| Drive Bay: | |
| Ext. 5.25" | 6 |
| Int. 3.5" | 3 (instead 3 x 3.5") |
| Dust | Front panel is equipped with dust filters |
| Front I/O Ports | 2 x USB 2.0 |
| Control &Indicator, LED | 1 x Power, 1 x HDD |
| Switch | POWER, RESET |
| Expansion Slots | 7 or 4 together wit ATX Power Supply |
| Cooling System: | 2 x 8 cm fan |
| PSU | 1U, 2U, ATX 8 cm fan |
| Recommended ExeGate PSU | ServerPRO-1U-F250AS, ServerPRO-1U-F250S, ServerPRO-1U-F300AS, ServerPRO-1U-F300S, ServerPRO-1U-F350AS, ServerPRO-1U-F350S, ServerPRO-1U-F400AS, ServerPRO-1U-F400S, ServerPRO-500ADS, ServerPRO-600ADS, ServerPRO-700ADS, ServerPRO-800ADS |
| Chassis material | 1.2 mm steel |
| Cases color | Black |
| Chassis color | Silver |
| Dimensions chassis(D x W x H), mm | 420 x 430 x 89 |
| Dimensions (D x W x H), mm | 452 x 482 x 89 |
| Net Weight w/o PSU / with PSU, kg | 6/7,3 |
| PSU | w/o PSU | 500W | 600W | 700W | 800W |
| P/N | EX279419 | EX279613 | EX279614 | EX279615 | EX279616 |
| EAN | 4895205108905 | 4895205108912 | 4895205108929 | 4895205108936 | 4895205108943 |
